CS-35E
10 kg payload bay for LiDAR and multispectral
- Endurance
- > 4 h (5 kg)
- Range
- 320 km
- Payload
- 10 kg
- Max. take-off weight
- 35 kg
CS-35V VTOL fixed-wing drone
10-hour endurance for long corridors and large areas
Business customers only. For lawful civilian commercial and professional applications. All orders are subject to business verification, product eligibility and applicable approvals.
Key data
- Endurance
- 10 h
- Range
- 930 km
- Payload
- 12 kg
- Max. take-off weight
- 35 kg
Before you order Approvals, export control and safe operation
Long-endurance aircraft and thermal payloads are reviewed for export control before an order is accepted; an end-user statement and a government permit may be required. Long-range flights need specific operating approvals. Docking stations are available on request under the same conditions. Export and end-use policy · Buyer's guide
Technical data
| Endurance | 10 h |
|---|---|
| Service ceiling | 5000 m |
| Range | 930 km |
| Max. take-off weight | 35 kg |
| Payload | 12 kg |
| Dimensions | 2360×700×3920 mm |
| Speed | 75–140 km/h |
| Wind resistance | 13 m/s |
| Control range | 30 km |
| Take-off / landing | Vertical take-off and landing |
| Sensor payload | Dual-sensor gimbal: 1080p zoom + 640 thermal |
| Features | Autonomous flight, return-to-home on link loss |
| Operating temperature | −20 … 55 °C |
Manufacturer data, measured under the manufacturer's test conditions. They do not confer any approval or operating right. The binding specification is confirmed in the order confirmation.
Compared with similar models
About this product line
Vertical take-off and landing removes the need for a runway or catapult. Fifteen airframes cover electric and fuel-powered versions from 10.5 to 175 kg take-off weight. According to the manufacturer, all support autonomous flight with return-to-home, tool-free assembly and a dual-sensor gimbal for daylight and thermal imaging.
Typical applications: VTOL fixed-wing drones for mapping and survey
Related models
Need a configuration that is not listed?
Payloads, batteries, spare parts and ground stations can be quoted on request, subject to availability. Describe the job and we propose a setup.
