CS-130E VTOL fixed-wing drone

Electric 130 kg class

Business customers only. For lawful civilian commercial and professional applications. All orders are subject to business verification, product eligibility and applicable approvals.

Endurance: 3 h
Range: 330 km
Payload: 30 kg
Max. take-off weight: 130 kg

Request a quote for CS-130E

Before you order Approvals, export control and safe operation

Long-endurance aircraft and thermal payloads are reviewed for export control before an order is accepted; an end-user statement and a government permit may be required. Long-range flights need specific operating approvals. Docking stations are available on request under the same conditions. Export and end-use policy · Buyer's guide

Technical data

Endurance	3 h
Service ceiling	5500 m
Range	330 km
Max. take-off weight	130 kg
Payload	30 kg
Wingspan	6.8 m
Max. speed	> 140 km/h
Cruise speed	110 km/h
Wind resistance	13 m/s
Take-off / landing	Vertical take-off and landing
Sensor payload	Dual-sensor gimbal: 1080p zoom + 640 thermal
Features	Autonomous flight, return-to-home on link loss
Operating temperature	−20 … 55 °C

Manufacturer data, measured under the manufacturer's test conditions. They do not confer any approval or operating right. The binding specification is confirmed in the order confirmation.

Compared with similar models

Model	Endurance	Range	Payload	Max. take-off weight	Service ceiling
CS-130E	3 h	330 km	30 kg	130 kg	5500 m
CS-130	8 h	880 km	30 kg	130 kg	4000 m
CS-160	> 8 h	880 km	40 kg	160 kg	5000 m

About this product line

Vertical take-off and landing removes the need for a runway or catapult. Fifteen airframes cover electric and fuel-powered versions from 10.5 to 175 kg take-off weight. According to the manufacturer, all support autonomous flight with return-to-home, tool-free assembly and a dual-sensor gimbal for daylight and thermal imaging.

Typical applications: VTOL fixed-wing drones for mapping and survey

All models in this line: VTOL fixed-wing drones
